Image Variations

FrankenPHP

The frankenphp variation runs FrankenPHP, an application server built on Caddy that runs PHP inside the web server process, with no PHP-FPM. Choose it for Laravel Octane and other worker-mode apps. It also gets Let's Encrypt certificates without a reverse proxy and serves HTTP/3. Compare every variation →

At a glance

frankenphp
ProcessesOne frankenphp process (Caddy with PHP built in). No supervisor.
Ports8080 (HTTP), 8443 (HTTPS over TCP, and HTTP/3 over UDP), 2019 (Caddy admin API, off unless CADDY_ADMIN sets it; Octane puts it on its own port, see Octane options)
Stop signalSIGTERM
Default health checkcurl to http://localhost:${CADDY_HTTP_PORT}${HEALTHCHECK_PATH} (/healthcheck by default)
Webroot variableCADDY_SERVER_ROOT (default /var/www/html/public)
PHP versions8.3 to 8.6. Not built for 8.1 or 8.2.
Operating systemsDebian and Alpine

The image also includes a Mercure hub, turned off by default.

Read FrankenPHP's known issues before you run it in production. They include slower performance on Alpine images. Use the Debian image unless you need Alpine.

Classic mode and worker mode

FrankenPHP starts in classic mode. Every request boots your app from scratch, as it would under PHP-FPM. Existing PHP apps run unchanged.

In worker mode, your app boots once and stays in memory between requests. The app must be written for it, because state left over from one request is still there for the next. For Laravel, run Octane with this image's Caddyfile; see Laravel Octane. For other frameworks, configure workers with FRANKENPHP_CONFIG as described in FrankenPHP's worker docs.

Quick start

Put your app's public files in public/, which is the default webroot:

compose.yml
services:
  php:
    image: serversideup/php:8.5-frankenphp
    ports:
      - "80:8080"
    volumes:
      - ./:/var/www/html

Run docker compose up and open http://localhost. Mounting your code like this is for development. In production, copy the code into your own image instead; see packaging your app for deployment.

Configuration

These variables are specific to this variation. Defaults and the full list, including every PHP_* option, are in the environment variable specification.

To changeSet
Document rootCADDY_SERVER_ROOT
Listening portsCADDY_HTTP_PORT, CADDY_HTTPS_PORT
Let's Encrypt certificatesCADDY_AUTO_HTTPS, CADDY_HTTPS_SERVER_ADDRESS, CADDY_ACME_PROFILE
Log format and destinationCADDY_LOG_FORMAT, CADDY_LOG_OUTPUT
Caddy admin APICADDY_ADMIN
FrankenPHP and php_server optionsFRANKENPHP_CONFIG, CADDY_PHP_SERVER_OPTIONS
Raw Caddyfile rulesCADDY_GLOBAL_OPTIONS, CADDY_SERVER_EXTRA_DIRECTIVES, or the folders in Adding your own Caddyfile rules
Mercure hubMERCURE_*, see Mercure

Adding your own Caddyfile rules

When the variables above don't cover a rule, add raw Caddyfile config at the level where it belongs. Every .caddyfile file in a folder is imported at that level:

LevelWhat goes hereVariableFolder
GlobalGlobal options, including Caddy's servers optionCADDY_GLOBAL_OPTIONS/etc/frankenphp/caddyfile-global.d/
ServerDirectives for your app, such as header, redir, and request matchersCADDY_SERVER_EXTRA_DIRECTIVES/etc/frankenphp/caddyfile-server.d/
New sitesExtra site blocks, such as a second domain or a reverse proxyNone/etc/frankenphp/caddyfile.d/

Use a variable for a one-liner and a folder for anything longer. Only the folders work with Laravel Octane, which replaces CADDY_GLOBAL_OPTIONS and CADDY_SERVER_EXTRA_DIRECTIVES with its own values.

This is where each one lands in /etc/frankenphp/Caddyfile:

/etc/frankenphp/Caddyfile
{
    frankenphp {
        FRANKENPHP_CONFIG
    }
    caddyfile-global.d/*.caddyfile
    CADDY_GLOBAL_OPTIONS
}

your app's site (one per listener that SSL_MODE creates) {
    php_server {
        CADDY_PHP_SERVER_OPTIONS
    }
    CADDY_SERVER_EXTRA_DIRECTIVES
    caddyfile-server.d/*.caddyfile
}

caddyfile.d/*.caddyfile

Add rules to your app

Put directives for your app in caddyfile-server.d/. This example gives one JavaScript file a one-hour cache instead of the one-year cache the image sets for static assets:

embed-cache.caddyfile
@embed path /embed.js
header @embed >Cache-Control "public, max-age=3600"

Mount the file in development. For production, copy it into your image:

services:
  php:
    image: serversideup/php:8.5-frankenphp
    volumes:
      - ./embed-cache.caddyfile:/etc/frankenphp/caddyfile-server.d/embed-cache.caddyfile

Rules in caddyfile-server.d/ apply on every listener SSL_MODE creates. With SSL_MODE=mixed that includes plain HTTP. Match on protocol https for rules that belong only on HTTPS.

Docker's health check goes through your app's site too. Leave the health check path out of any rule that matches every request, such as basic_auth or redir, or the container is marked unhealthy:
basic-auth.caddyfile
@protected not path /healthcheck {$HEALTHCHECK_PATH:/healthcheck}
basic_auth @protected {
    admin $2a$14$KbVXTcgF3ZrK76FfvPLFj.kXOV/PH5pkAk.o53ct8bGdsl6yai9eC
}
Generate the password hash with docker run --rm -it serversideup/php:8.5-frankenphp frankenphp hash-password.

Add another site

Files in caddyfile.d/ sit at the top level of the Caddyfile, outside your app's site. Use them for a whole new site block:

docs-proxy.caddyfile
http://docs.example.com:{$CADDY_HTTP_PORT:8080} {
    reverse_proxy docs:3000
}

Rules for your app fail here with "request matchers may not be defined globally". Put those in caddyfile-server.d/.

Replace the whole Caddyfile

Copy your own file over /etc/frankenphp/Caddyfile only if the folders can't do what you need. You then own everything the image's Caddyfile does, including SSL modes, security headers, and the health check endpoint.

Automatic HTTPS

FrankenPHP can get and renew a Let's Encrypt certificate itself. Set CADDY_AUTO_HTTPS=on and SSL_MODE=full, and put your domain (such as example.com) in CADDY_HTTPS_SERVER_ADDRESS. The server must be reachable from the internet on ports 80 and 443. See configuring SSL for the full Compose file and the volumes that keep certificates across deployments.

Without automatic HTTPS, SSL_MODE=mixed serves HTTP on 8080 and HTTPS on 8443. SSL_MODE=full serves HTTPS on 8443 and redirects HTTP on 8080 to it. Both use a self-signed certificate unless you provide one.

Health checks

The default health check works without configuration. Set HEALTHCHECK_PATH=/up to check Laravel's health route instead. Health checks covers timing and orchestrators. Laravel health checks covers /up and worker containers.

Logging

  • Caddy writes request logs and errors to stderr, as JSON when no terminal is attached (Compose, Swarm, Kubernetes) and as readable console lines with docker run -it. Set CADDY_LOG_FORMAT to json or console to use one format everywhere. Under Laravel Octane, leave CADDY_LOG_FORMAT and CADDY_LOG_OUTPUT at their defaults, because Octane only reads JSON on stderr.
  • LOG_OUTPUT_LEVEL defaults to info in this variation, so request logs are included. Set it to warn to log problems only.

See default configurations for how logging differs across variations.

Mercure

Mercure pushes real-time updates from your app to the browser. FrankenPHP has a Mercure hub built in. Turn it on with environment variables. The hub answers at /.well-known/mercure on the same ports as your app, in classic mode and with Laravel Octane.

compose.yml
services:
  php:
    image: serversideup/php:8.5-frankenphp
    ports:
      - "80:8080"
    volumes:
      - ./:/var/www/html
    environment:
      MERCURE_ENABLED: "true"
      MERCURE_TRUSTED_ISSUERS: "https://example.com"
      MERCURE_PUBLISHER_JWT_KEY: "${MERCURE_JWT_SECRET}"
      MERCURE_SUBSCRIBER_JWT_KEY: "${MERCURE_JWT_SECRET}"

Docker Compose reads MERCURE_JWT_SECRET from your .env file. Generate one with openssl rand -base64 32. The hub only accepts subscribers with a valid token; to allow anonymous subscribers or set CORS origins, add Mercure directives with MERCURE_EXTRA_DIRECTIVES:

compose.yml
    environment:
      MERCURE_EXTRA_DIRECTIVES: |
        anonymous
        cors_origins https://example.com
FrankenPHP 1.13 includes Mercure 1.0, which expects OAuth 2.0 access tokens with iss, aud, and exp claims. If your app still signs Mercure 0.x tokens, set MERCURE_EXTRA_DIRECTIVES: "protocol_version_compatibility 8" while you migrate, then remove it, because it relaxes token checks.

The other MERCURE_* variables, such as the JWT algorithms, are in the environment variable specification.
